316 Stainless Steel Rolled Fin Piping for Server Liquid Cooling

Servers are getting more powerful. That means they produce more heat. To deal with this, we need a reliable cooling system, and our Server Finned Liquid Cooling Tubes are engineered to meet this exact need. This product is a 316 Rolled fin stainless steel tube, crafted from 316 stainless steel — a strong, highly corrosion-resistant material. The tube has a rolled fin structure, which helps to increase the area for heat transfer. This design does not use welds or brazed joints, making it more reliable. The fins are made directly from the tube wall, creating a thermally continuous structure. This design is ideal for high-density computing environments. Compared to smooth-bore cooling tubes, the finned geometry increases the coolant contact area. This helps to remove heat from processor plates and direct it to facility chillers.
The 316 grade of steel has a high level of corrosion resistance. It contains molybdenum, which provides enhanced protection against corrosion. This makes the 316 finned liquid cooling tube suitable for use in closed-loop systems where coolant chemistry may vary.

Send Inquiry

Product Introduction

Product Specifications

Parameter	Specification
Material	316 Stainless Steel
Outer Diameter	Φ12 mm – Φ530 mm
Wall Thickness	0.1 mm – 40 mm
Standard Length	6 m / piece
Fin Type	Rolled fin
Tensile Strength	≥ 50 kgf/mm²
Elastic Modulus	200 GPa
Operating Temperature	−200 °C to +600 °C
Pressure Rating	≥ 200 kgf/cm²
Surface Treatment	Acid-washed / electropolished
Shape Options	Round, square rectangular
Standard Compliance	ASME B31.3 pressure piping standard

Product Advantages

1 Exceptional Corrosion Resistance: The 316 stainless steel piping has a high level of corrosion resistance.This is due to the presence of molybdenumwhich provides protection against chloride pitting and crevice corrosion.

2 Rolled Fin Technology. Maximum Heat Transfer, Zero Joint RiskThe rolled fin technology used in this pipingprovides a level of heat transfer and eliminates joint risk.The fins are made directly from the tube wall,which eliminates thermal resistance.

3 High Structural Integrity Under Demanding Operating Conditions The piping has a high tensile strength and elastic modulus making it suitable for use in demanding operating conditions.It can withstand high-pressure pulses, vibration and thermal cycling.

4 Low Flow Resistance, Clean Inner Surface, Easy MaintenanceThe piping has an inner surface, which reduces hydraulic resistance and prevents scale buildup.This makes it easy to maintain and clean.

Custom Purchase Suggestions

* When ordering specify the configurationto reduce lead time and avoid on-site rework.

* Consider the diameter, wall thickness,fin geometry, length and bends.

Application Areas

The primary use case is liquid cooling in high-density server racks.The finned surface pulls heat from CPU/GPU plates and transfers it efficiently to facility chillers.

FAQ

Q1: Why choose 316 stainless over 304 for Server Finned Liquid Cooling Tubes in server cooling applications?

A1: The molybdenum in 316 resists pitting and crevice corrosion.

Q2: How does the construction of a 316 Rolled fin stainless steel tube differ from welded fin tubes?

A2: Rolled fins are formed from the tube wall itself, eliminating thermal resistance and joint failure risk.

Q3: What customization options are available?

A3: Various customization options are available, including diameters, wall thicknesses, cut lengths and bend geometries.

Q4: What quality testing is performed before shipment?

A4: Each production batch undergoes pressure testing.

Q5: Is a 316 finned liquid cooling tube compatible with standard server rack cooling manifolds?

A5: Yes, it is fully compatible with standard server rack cooling manifolds.
